Technical Specifications

Mechanical
Dimensions Ø160 x 31.45 mm (Ø6.3 x 1.2")
Weight Without mount: 170 g (6 oz)
With mount: 185 g (6.5 oz)
Hardware
Networking interface (1) GbE RJ45 port
Management interface Ethernet
Power method PoE
Passive PoE, 24V (Pairs 4, 5+; 7, 8 return)
Power supply UniFi PoE switch
24V, 0.5A Gigabit PoE adapter*
*5-packs do not come with PoE adapters.
Max. power consumption 6.5W
Max. TX power
2.4 GHz
5 GHz
6 GHz

20 dBm
20 dBm
MIMO
2.4 GHz
5 GHz
6 GHz

2 x 2
2 x 2
Throughput rate
2.4 GHz
5 GHz
6 GHz

300 Mbps
867 Mbps
Antenna gain
2.4 GHz
5 GHz
6 GHz

3 dBi
3 dBi
Button Factory reset
Mounting Wall, ceiling (Included)
Ambient operating temperature -10 to 70° C (14 to 158° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11 a/b/g/n/r/k/v/ac
Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID Up to 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Power save Supported
WMM Voice, video, best effort, and background
Concurrent clients 250+
Supported Data Rates (Mbps)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
